Semco SI BCDS 100V 30A 2CH

Product Description

The equipment is mainly usedto test battery charging and discharging and related battery characteristicsand the test channels are completely independent through software programmingcontrol customers can charge and discharge batteries at any current and voltagewithin the range of programming

Safety protection theequipment has the functions of output anti reverse connection abnormal voltagesampling line and abnormal current test line detection and protection when thevoltage sampling line falls off or disconnects and the current line contactspoorly the equipment detects the abnormality in time and suspends the testchannel it has power off protection overcurrent protection overvoltageprotection and overtemperature protection which can ensure the safety of test

The process flow can customizevariables to participate in programming realize a variety of combined testschemes and support multiple loop nesting

Single point independence eachchannel has an independent programmable constant current source and constantvoltage source which can independently set the test step operation

Interrupt connection under anycircumstances such as sudden power failure communication interruption or otherabnormal reasons after the channel stops the next time the condition isrestored the work step has automatic connection and forced connection operationfunctions

Abnormal capture which canaccurately capture the details of voltage and current changes for example whenthe current and voltage changes beyond a certain range the equipment canautomatically

Generate alarms and suspendtests

Log tracking with log functionincluding records in the whole test process and exception records which can beused for tracing and exception query in the test process

Curve analysis and processingfree selection of cycles to be displayed and free combination of various curves

The equipment current outputadopts soft start mode to avoid the thermal shock of the battery and connectorcaused by instantaneous output of large current surge

CC CV charging CC CV has nogap transition and no voltage and current impact during charging process whichcan prevent PCB protection caused by peak current impact of battery

The charging and dischargingsteps are started by soft start without current impact at the moment of startand the transition of constant current and constant voltage switching is smoothwithout spike and sudden wave

Exclusive overchargeprotection during the charging process of the battery pack when the protectionboard is abnormal or other protection boards are disconnected the instantaneouspulse voltage at the protection board end or the battery end will not exceed 10V
