Semco SI 10C SMBR 32700 - Ten Channel Automatic Sorting with Bar Code Scanner

1525000.00 INR/Unit

Get a Price/Quote

Product Details:

Rated Voltage AC 220V±10%/50Hz, power: ≤1.5 KW Volt (V)
Dimension (L*W*H) 59X35X62 Inch (in)
Function (1) Voltage internal resistance test (2) Barcode Scanning (3) Ten-gear sorting (4) Separation efficiency: ≥3500 pieces/hour
Weight 300 Kilograms (kg)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Semco SI 10C SMBR 32700 - Ten Channel Automatic Sorting with Bar Code Scanner Price And Quantity

Price 1525000.00 INR/Unit
Minimum Order Quantity 1 Unit

Semco SI 10C SMBR 32700 - Ten Channel Automatic Sorting with Bar Code Scanner Product Specifications

Weight 300 Kilograms (kg)
Dimension (L*W*H) 59X35X62 Inch (in)
Function (1) Voltage internal resistance test (2) Barcode Scanning (3) Ten-gear sorting (4) Separation efficiency: ≥3500 pieces/hour
Rated Voltage AC 220V±10%/50Hz, power: ≤1.5 KW Volt (V)

Semco SI 10C SMBR 32700 - Ten Channel Automatic Sorting with Bar Code Scanner Trade Information

Supply Ability 10 Unit Per Day
Delivery Time 5 Days
Main Domestic Market All India

Product Description

(1) Feeding method: manually load the battery to the feeding hopper

(2) Receiving method: ten-speed manual receiving

(3) Test station: test 1 battery at a time

(4) Scanning station: 1 battery per scan

(5) Sorting method: the stepper motor transfers the battery one grid at a time, and the cylinder pushes the battery to the receiving gear

(6) Sorting system: Panasonic PLC + industrial computer
